LR046C-75 – RECESSED LINEAR LIGHT 75MM IP44

FEATURES

• PC Opal diffuser

• Energy saving of 35% to a T5 FTL

• Size 50x70mm aluminium housing

• 85% light through Opal diffuser

• Aluminium PCB with high thermal conductivity for fast heat dissipation

• Protection: short circuit, open circuit, open current, one voltage, excessive temperature

• CCT 2700k – 6500k (4000k or 6500k standard)

• Standard LENGTH 600mm;1200mm and 2400mm

• Typical Luminous Efficacy 120lm per watt

• THD<15%

• Driver efficiency >90%

• SAMSUNG 2835 LED chip

• Chip: Samsung

• 3 year or 5 year warranty

• IP44 body

• Beam angle 120° with uniform light dispersion

• Color rendering index (CRI) >80

• Rated life 50 000Hrs (Ta =30°C@L70)

• Driver Efficiency: 93%

• Power Factor: >0.9

• Surge protection: 1KVA

• External driver

• Bespoke manufacturing

APPLICATIONS

• Retail Lighting

• Commerical Lighting

• Office Lighting – Interior Decor
